Brass Pogo Pin Connector Spring Loaded Electrical Contact Pins 1 / 3 / 6mm
Product Description :
Flat SMT Type :
Stable quality . The bottom of barrel is designed as flat shape,easy to be mounted on PCB.
Plug DIP Type :
With positioning pin on the bottom of barrel . Hard to shift after mounted on PCB Good performance on positioning .
Right angle Type :
Bending tail of barrel offers more choices on space adjustment.
Double-Ended Type :
Double - ended design offers engineers to have more choices of flexible space adjustment on board - to - board connection .
Solder Cup Type :
Except the standard specification , we also provide the customization service for customers special needs in pogo pin connector field .
Application :
1) Mobile communication
2) Mobile PC,
3) GPRS
4) Electronic education
5) Handheld computers
6) Digital cameras
7) Car electronics
8) Medical equipment and 3 C electronics and other fields
Features :
Antenna connection
- smaller distributed capacity and inductance for high frequency signal
- smaller attenuation
- more stable signal connection
Wristband charging connection
- skin allergy free
- nick free
- water proof
- sweat proof
Specifications :
| Material |
| Barrel | Brass C3604 gold |
| Plunger | Brass C3604 |
| Spring | SUS304 |
| Plating |
| Barrel | 5u’’AU over 50-80 u’’Ni |
| Plunger | 5u’’AU over 50-80 u’’Ni |
| Spring | 5u’’AU over 50-80 u’’Ni |
| Electrical |
| Rated voltage & current | DC 12V,1-10A |
| Contact resistance | 50mohm max.at working height |
| Mechanical |
| Force | 110g±20% at working stroke |
| Full stroke | 1mm-6mm |
| Durability | 10,000 cycles(min) |
About us :
1. We specialize in RF connectors , RF cable assembly and RF connectors . The main products we manufacture are RF connectors, MCX , MMCX , SMA , SMB , N , Pogo pin and RF connector cable . Our products are sold to different areas of overseas markets .
2. We have passed ISO9001 quality certification and our products
antenna connector comply with RoHS requirement .
3. We have professional technical development team . we have advanced NC processing equipment and precise test equipment .
4. Our principle is to meet customers’ requirement by good service and high-quality products . The prices of products….. are very competitive and reasonable .
5. We are committed to providing the best products….. to our customers with quickest delivery and best price .
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation!!!
